28 Panel (12.3kW) Complete DIY Solar Kit

28 Panel (12.3kW) Complete DIY Solar Kit

$9,283.80

This DIY solar kit contains everything you need to install grid-tie solar on your roof in Canada (panels, microinverters, and racking). Check out our DIY Solar Guide for complete instructions.

Installation instructions, datasheets and warranty sheets are listed below.

JA Solar JAM54D41-440/LB, 440W, Bifacial
JA Solar JAM54D41-440/LB, 440W, Bifacial
$113.90
Longi LR5-54HPB-410M, 410W, Monofacial
Longi LR5-54HPB-410M, 410W, Monofacial
$133.50
JA Solar JAM60D41-500/LB, 500W, Bifacial
JA Solar JAM60D41-500/LB, 500W, Bifacial
$135.60
APSystems DS3-S 640W Microinverter
APSystems DS3-S 640W Microinverter
$218.10
APSystems DS3-L 768W Microinverter
APSystems DS3-L 768W Microinverter
$234.40
APSystems DS3 Series AC Trunk Cable, #10AWG
APSystems DS3 Series AC Trunk Cable, #10AWG
$38.00
Kinetic Solar Microinverter Top Mount Kit
Kinetic Solar Microinverter Top Mount Kit
$3.70
APSystems ECU-R Wireless (Energy Communication Unit)
1 × APSystems ECU-R Wireless (Energy Communication Unit)
$217.00
APSystems DS3 Series AC Trunk End Cap
APSystems DS3 Series AC Trunk End Cap
$9.30
Kinetic Solar KRAPID1-140M, Rapid Rail 140" (11'7" long) 3556mm
Kinetic Solar KRAPID1-140M, Rapid Rail 140" (11'7" long) 3556mm
$43.40
Kinetic Solar KRAPID1-185M, Rapid Rail 185" (15'4" long) 4699mm
Kinetic Solar KRAPID1-185M, Rapid Rail 185" (15'4" long) 4699mm
$58.60
Kinetic Solar KFLK-4S Flashing Kit with 1 x 4" Self-Drilling Lag Bolt
Kinetic Solar KFLK-4S Flashing Kit with 1 x 4" Self-Drilling Lag Bolt
$9.50
Kinetic Solar 3" L Bracket Kit
Kinetic Solar 3" L Bracket Kit
$4.30
Kinetic Solar Joiner
Kinetic Solar Joiner
$5.90
Kinetic Solar End Clamp, Adjustable from 30-46mm (Black)
Kinetic Solar End Clamp, Adjustable from 30-46mm (Black)
$7.00
Kinetic Solar Mid Clamp, Adjustable from 30-46mm (Black)
Kinetic Solar Mid Clamp, Adjustable from 30-46mm (Black)
$5.80
Kinetic Solar Ground Lug Kit
Kinetic Solar Ground Lug Kit
$5.10
Kinetic Solar KCMS15-C 1.5" Cable Management Clip
Kinetic Solar KCMS15-C 1.5" Cable Management Clip
$0.50
Kinetic Solar KHSG6-M Rodent Guard Mesh, Black, 6" Wide, 100 feet rolls
Kinetic Solar KHSG6-M Rodent Guard Mesh, Black, 6" Wide, 100 feet rolls
$102.00
Kinetic Solar KGRGCLP-B, Rodent Guard Clip, 68 Pack
Kinetic Solar KGRGCLP-B, Rodent Guard Clip, 68 Pack
$177.90
Placeholder
Roof sealant (Geocel, Soudal or Henry brand), black, 300ml cartridge
$11.20
EZ Solar Junction Box, JB-1.2, Asphalt Shingle
EZ Solar Junction Box, JB-1.2, Asphalt Shingle
$73.80
EZ Solar JB-3 Rooftop PV Junction Box, Rail Mount
EZ Solar JB-3 Rooftop PV Junction Box, Rail Mount
$62.90
Solar Circle Co-op Membership
1 × Solar Circle Co-op Membership
$50.00
SKU: solar-kit-28p Category:
Before ordering this solar kit, it is highly recommended to review all the steps in the DIY Solar Guide. Especially the Design Specifics sections.

Why? Because this solar kit was designed using a simple two or three-row portrait layout, but the best design for your roof likely does not match this layout. For this reason, you should use the Kinetic Solar Configurator Tool to verify/customize the count of which components (especially the rails) are in this solar kit.

Design / Installation Instructions for this solar kit:

The above solar kit is paired with JA Solar JAM54D41-440, 440W panels and APSystems DS3-S (640W) microinverters. This default design has a DC/AC ratio of 1.38. To understand DC/AC ratios and figure out which solar panel and microinverter pairing works best for you, read more here.

28 Panel Solar Kit Single Line Diagram (SLD) DS3-S Template
28 Panel Solar Kit Single Line Diagram (SLD) DS3-L Template
Kinetic Solar Racking Install Instructions
APSystems Microinverter Install Instructions
APSystems ECU-R User Manual

Datasheets for this solar kit:

APSystems Datasheet
Longi LR5-54HPB 410W Datasheet
JA Solar JAM54D41-440/LB, 440W Datasheet
JA Solar JAM60D41-500/LB, 500W Datasheet

Warranty files for this solar kit:

APsystems Policy on Non-Professional Self-Installers (yes, DIY is covered)
Kinetic Solar Racking Warranty (20 years)
APsystems Warranty Canada (25 years standard)

Other questions:

If you’ve read the DIY Solar Guide, reviewed the FAQ Section and still have an unanswered question, please post it in the forum and we’ll do our best to answer quickly!
